Francis L230RC 100W LED is a compact remote control marine searchlight for patrol craft, coast guard, workboats and smaller professional vessels. It delivers approximately 1,357 m range at 1 lux with a fixed 4° beam and 7,047 lumens.
Available for 24V, 110/115V or 240V installations with remote pan and tilt.
Spare parts and RFQ
Francis manual C29433 contains technical and spare-parts information for the L230RC 100W LED family. Confirm the product number and serial number before ordering replacement components.
Compare Francis searchlights, find spare parts or request a quotation
The Francis L230RC 100W LED is a compact remote control marine searchlight for patrol craft, coast guard, workboats and smaller professional vessels.
Technical specification
- LED power: 100W
- Supply: 24V, 110V or 240V
- Range at 1 lux: approximately 1,357 m
- Beam divergence: 4° fixed focus
- Luminous flux: approximately 7,047 lm
- LED life: approximately 30,000 hours
- Pan rotation: 365°
- Tilt: ±20°
- Pan speed: approximately 24°/s
- Tilt speed: approximately 4°/s
- Searchlight protection: IP66
- Joystick protection: IP65
- Searchlight weight: approximately 11 kg
Francis part numbers
- A7297 – 24V
- A7299 – 110V
- A7298 – 240V
