Francis L480RC Halogen Lite is a variable speed remote control 1–2kW marine searchlight with up to approximately 1,643 m range at 1 lux, Francis FBUS / RS485 and optional remote focus.
Spare parts and RFQ
Francis FBUS uses RS485 bidirectional communication. Remote focus is available on the relevant configurations, and the current C27447 user manual includes installation, wiring, general assemblies and spare parts information. Always confirm the product number and serial number before ordering replacement components.
Compare Francis searchlights, find spare parts or request a quotation
Francis L480RC Halogen Lite
The Francis L480RC Halogen Lite is a large variable speed remote control searchlight for patrol craft, tugboats, custom vessels and other professional marine applications. The current Francis platform combines a parabolic glass reflector, marine grade construction and Francis FBUS / RS485 bridge control.
Technical specification
- Light source: Tungsten halogen
- Power: 1000W or 2000W
- Supply: 115V or 240V AC
- Range at 1 lux: approximately 1,440–1,441 m at 1kW and 1,533–1,643 m at 2kW depending on voltage
- Beam divergence: 4.5° at 1kW and 6.5° at 2kW
- Luminous flux: approximately 21,000–23,500 lm at 1kW and 52,000–56,000 lm at 2kW
- Pan rotation: 385°
- Tilt: +30° to -35°
- Pan speed: variable 1–23°/s
- Tilt speed: variable 1–8°/s
- Ingress protection: IP66
- Operating temperature: -20°C to +50°C, with lower temperature configuration available on request
- Searchlight weight: approximately 43 kg
Francis part numbers and lamps
- A7116 – L480RC 115/240V 1kW variable speed remote control
- A7117 – L480RC 115/240V 1kW remote focus variable speed remote control
- A7118 – L480RC 115/240V 2kW variable speed remote control
- A7119 – L480RC 115/240V 2kW remote focus variable speed remote control
Documented lamp references include D1809, D6715, D20390 and D20236 depending on voltage and wattage.
